Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5

Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5

Large Image :  Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5

Product Details:
Place of Origin: china
Brand Name: HR
Certification: ceiso
Model Number: M5
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: usd3200-4000
Packaging Details: wooden packing
Delivery Time: 30day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 40set/month
Contact Now

Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5

Description
NAME: M5 Vertical Turret Milling Machine Workbench Area: 1370*254
X Axis（mm）: 880-980 Y Axis（mm）: 380-420
Z Axis（mm）: 330-360 Spindle Travel（mm）: 127
Spindle Speed: 16 Net Weight（kg）: 1300
Highlight:

Benchtop horizontal vertical milling machine

,

M5 horizontal vertical milling machine

,

M5 benchtop vertical mill



Automatic Turret Vertical Milling Center Machine M5

Product Description
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 0
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 1
Machine model
M 5
Workbench area
1370*254
1370*305
Travel
X axis(mm)
880-980
780-850

Y axis(mm)
380-420
360-380

Z axis(mm)
330-360
330-360
Spindle
Spindle taper
R8 NT30 NT40

Spindle travel(mm)
127

Spindle speed
16

Spindle feed(mm)
0.076 / 0.003 0.038 / 0.0015 0.203 / 0.008

Spindle low speed(r/min)
66,110,175,270,550,930,1460,2270

Spindle high speed(r/min)
132,220,350,540,1100,1860,2920,4540
T Slot
Number of slots X width(mm)
3X16

T-slot spacing(mm)
76
Motor
Voltage(V)
380

frequency(HZ)
50

head voltage
3HP / 2.2KW 5HP / 3.7KW

Ramp voltage
1.1Kw
maximum working weight(Kg)
350
Overall dimension(mm)
1800* 1780*2350
net weight(kg)
1300
Features:
1. Taiwan Turret milling head;
2. The guide rail is super-audio quenched, precision ground and scraped;
3. Automatic lubrication system can reduces creep at low speed, reduces machine wear, improves accuracy and extends machine life;
4. Head rotation rotation 90°(left and right),head rotation 45°(back and forth)；

Company information
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 2


sample
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 3
Packaging＆Shipping
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 4

Packaging Details: 1. Outside package: Standard marine export plywood case. 2. Inner package: Stretchy film and plastic film for humidity. We can package according to your requests. Delivery Detail: Shipped in 20-30 working days after payment.
Certifications
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 5

All products are available upon request, with or without trademarks. If you need OEM service with your own brand or product, please let us know. If you have any other specific requirements, please feel free to contact us. Our factory has obtained the import and export license issued by the Ministry of foreign trade, and passed the iso9001 quality management system certification and CE certification. In the quality layer by layer, we will wholeheartedly serve for the majority of customers.
customer visiting
Taiwan Horizontal Vertical Milling Machine Mini Universal Benchtop Vertical Mill M5 6

We welcome customers to visit the factory, we will have customers to visit the factory and customers online purchase feedback, through feedback learning experience, continuous progress, better service for you.Shandong Honest is willing to unremitting pursuit and efforts, hand in hand with merchants to create a brilliant future
FAQ

1.Q: Which trade term I can choose?
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.

2.Q: How can I get quotation from you?
A: You can make the inquiry online , or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.

3.Q: how can I make the payment?
A: We can make the deal online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.

4.Q: How long does it take to get machine?
A:It takes about 10 days.

We want to know:
Please tell us your specific purchasing requirements, so that we can make specific quotations.



Tag:

horizontal shaper machine,

benchtop milling machine for steel,

cnc turret milling machine
