M4 Vertical Turret Milling Machine Small Cnc

M4 Vertical Turret Milling Machine Small Cnc
M4 Vertical Turret Milling Machine Small Cnc M4 Vertical Turret Milling Machine Small Cnc M4 Vertical Turret Milling Machine Small Cnc

Large Image :  M4 Vertical Turret Milling Machine Small Cnc

Product Details:
Place of Origin: china
Brand Name: HR
Certification: ce iso
Model Number: M4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: usd2900-4000
Packaging Details: wooden packing
Delivery Time: 30day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 40set/month
Contact Now

M4 Vertical Turret Milling Machine Small Cnc

Description
NAME: M4 Turret Type Milling Machine Manufacturer Sales Workbench Area: 1270*254
X Axis（mm）: 780-850 Y Axis（mm）: 380-420
Z Axis（mm）: 350-380 T-slot Spacing（mm）: 65
Voltage（V）: 380 Net Weight（kg）: 1200
Highlight:

m4 cnc turret milling machine

,

cnc vertical turret milling machine

,

m4 vertical turret milling machine

Product Paramenters
M4 Vertical Turret Milling Machine Small Cnc 0
M4 Vertical Turret Milling Machine Small Cnc 1
Machine model
M4
Workbench area
1270*254
1370*254

travel
X axis(mm)
780-850
880-980
Y axis(mm)
380-420
380-420
Z axis(mm)
350-380
350-380



Spindle
Spindle taper
R8 NT40
Spindle travel(mm)
127
Spindle speed
16
Spindle feed(mm)
0.076 / 0.003 0.038 / 0.0015 0.203 / 0.008
Spindle low speed(r/min)
66,110,175,270,550,930,1460,2270
Spindle high speed(r/min)
132,220,350,540,1100,1860,2920,4540

T slot
Number of slots X width(mm)
3X16
T-slot spacing(mm)
65


motor
Voltage(V)
380
frequency(HZ)
50
head voltage
3HP / 2.2KW
Ramp voltage
1.1Kw
maximum working weight(Kg)
350
Overall dimension(mm)
1800* 1780* 2350
net weight(kg)
1200
Optional accessories
M4 Vertical Turret Milling Machine Small Cnc 2



Application The machine can be used both for vertical milling and horizontal milling, with corresponding attachments, it can also mill various rotary surfaces and grooves, etc. Two-section revolving cutter head enables the spindle to revolve and adjust at any angle, and mill complicated parts with multi-angle and multi-face by one time of holding. It is the ideal machining equipment for the industries of mechanic manufacture, mould, automobiles and motorcycles

Packaging＆Shipping
M4 Vertical Turret Milling Machine Small Cnc 3
1. Outside package: Standard marine export plywood case.
2. Inner package: Stretchy film and plastic film for humidity. We can
package according to your requests. Delivery Detail: Shipped in 15-30 working days after payment.
Company information
Shandong Honest control machine tool Co., Ltd. is a production-oriented enterprise with import and export rights. The company is equipped with many kinds of machine tools and equipment, including nearly 100 sets of large, fine and sophisticated equipment. The enterprise has 100 employees at present, including more than 10 engineers and dozens of workers and technicians. The company has been insisting on staff training for many years, through changing staff concepts, implementing enterprise reform, introducing new management concepts and methods, using modern management level. The company has hundreds of sales outlets, more than one sales branch or office, 30 provinces, cities, autonomous regions. In Europe, South America, Asia, Hong Kong and other countries and regions have long-term cooperation dealers. In recent years, the company insists on changing the mode and adjusting the structure; Implement brand strategy and expand foreign market; Control the manufacturing level of company equipment. Formed by CNC lathe, CNC milling machine, vertical machining center, gantry machining center, CNC metal band sawing machine, drilling and milling machine series, milling machine series, turret milling machine series, more than ten categories, hundreds of varieties of production scale. It has achieved the expected goal of CNC product serialization and characteristic product individuation, and formed its own brand while meeting the personalized needs of users.
M4 Vertical Turret Milling Machine Small Cnc 4
Exhibition
M4 Vertical Turret Milling Machine Small Cnc 5

FAQ

1. What is your minimum order quantity and warranty?
MOQ is one set, and warranty is one year.
2. Payment Terms
30% by T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss.
3. How can I choose the most suitable machines?
Please tell us your requirement of the machine, or you can also send us the products drawing, our engineer can help to choose the best model for you.
